IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 228
B03-15 Ref Source 2 0 0–4 - Page 76
B03-16 Run Source 2 0 0–3 - Page 76
B03-21 PG Start Sel 0 0, 1 - Page 76
B05-01 Accel Time 1 5.0* 0.0–25.5**** sec Page 77
B05-02 Decel Time 1 3.0* 0.0–25.5**** sec Page 77
B05-03 Accel Time 2 10.0 0.0–25.5**** sec Page 77
B05-04 Decel Time 2 10.0 0.0–25.5**** sec Page 77
B05-05 Acc Time N Chg 2.0 0.0–25.5 sec Page 78
B05-06 Dec Time N Chg 2.0 0.0–25.5 sec Page 78
B05-08 Fast Stop Time 0.5 0.0–25.5 sec Page 78
B05-10 Acc/Dec SW Freq 0.0 0.0–150.0 Hz Page 78
B05-11 SW Freq. Compare 1 0, 1 - Page 78
B05-12 Accel Time 3 3.0 0.0–25.5**** sec Page 78
B05-13 Decel Time 3 3.0 0.0–25.5**** sec Page 78
B05-14 Accel Time 4 3.0 0.0–25.5**** sec Page 78
B05-15 Decel Time 4 3.0 0.0–25.5**** sec Page 78
B05-16 Acc/Dec Ext Rang 0 0, 1 - Page 78
B08-01 Jump Freq 1 0.0 0.0–150.0 Hz Page 79
B08-02 Jump Freq 2 0.0 0.0–150.0 Hz Page 79
B08-03 Jump Freq 3 0.0 0.0–150.0 Hz Page 79
B08-04 Jump Bandwidth 1.0 0.0–20.0 Hz Page 79
B09-03 Field Forcing Selection 0 0, 1 - Page 80
B09-06 Field Forcing Limit 200 100–400 % Page 80
C01-01 Quick Stop 0* 0, 1 - Page 82
C01-02 Quick Stop Time 1.0 0.0–25.5 sec Page 82
C01-03 Reverse Plug 0 0, 1 - Page 83
C01-04 Rev-Plg Dec Time 2.0 0.0–25.5 sec Page 83
C01-05 Rev-Plg Acc Time 0.0 0.0–25.5 sec Page 83
C02-01 MicroSpd Gain 1 1.00
H: 0.01–1.00
T: 0.01–2.55
- Page 84
C02-02 MicroSpd Gain 2 1.00
H: 0.01–1.00
T: 0.01–2.55
- Page 84
C03-01 UL1 Speed 6.00 0–E01-04 Hz Page 85
C03-02 UL1 Decel Time 1.0 0.0–25.5**** sec Page 85
C03-03 UL2 Stop Time 1.0 0.0–25.5**** sec Page 85
C03-04 LL1 Speed 6.00 0–E01-04 Hz Page 85
C03-05 LL1 Decel Time 1.0 0.0–25.5**** sec Page 85
C03-06 LL2 Stop Time 1.0 0.0–25.5**** sec Page 85
C03-07 Lmt Stop Method 2* 0–2 - Page 85
C03-08 UL3 Stop Method 4 0–5 - Page 85
C03-09 UL3 Decel Time 1.0 0.0–25.5 sec Page 85
C03-10 Phantom Stop Met 1 0–2 - Page 86
Parameter Parameter Name Default Range Units Reference
