Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 239
H05-12 Run CommandSel 0 0, 1 - Page 164
H05-17 Busy Enter Sel 0 0, 1 - Page 164
H05-18 MtrSpd Monitor T 0 0–100 ms Page 164
H06-01 Pulse Input Sel 0 0, 5–7 - Page 165
H06-02 Pulse In Scale 1440 1000–32000 Hz Page 165
H06-03 Pulse Input Gain 100.0 0.0–1000.0 % Page 165
H06-04 Pulse Input Bias 0.0 -100.0–100.0 % Page 165
H06-05 Pulse In Filter 0.10 0.00–2.00 sec Page 165
H06-06 Pulse Output Sel 102 0–120 - Page 165
H06-07 Pulse Out Scale 1440 0–32000 Hz Page 165
H06-08 Pulse Min Freq 0.5 0.1–1000.0 Hz Page 165
H06-09 Pulse Dev Detect 5.0 0.0–25.5 % Page 165
L01-01 Mtr OL Charact 3 0–3 - Page 166
L01-02 MOL Time Const 1.0 0.1–5.0 min Page 166
L01-03 Mtr OH Alarm Sel 3 0–3 - Page 167
L01-04 Mtr OH Fault Sel 1 0–2 - Page 167
L01-05 Mtr Temp Filter 0.20 0.00–10.00 sec Page 167
L01-13 Mtr OL Mem Sel 1 0, 1 - Page 167
L02-01 PwrL Selection 0 0–2 - Page 167
L02-02 PwrL Ridethru t ** 0.0–25.5 sec Page 167
L02-03 PwrL Baseblock t ** 0.1–5.0 sec Page 167
L02-04 PwrL V/F Ramp t ** 0.0–5.0 sec Page 167
L02-05 PUV Det Level
Determined
by E01-01
230V: 150–210
460V: 300–420
575V: 431–604
VDC Page 167
L03-01 StallP Accel Sel 1 0–2 - Page 168
L03-02 StallP Accel Lvl
Determined
by D10-01
0–150 % Page 168
L03-03 StallPAcc LowLim 50 0–100 % Page 168
L03-05 StallP Run Sel 1 0–2 - Page 168
L03-06 StallP Run Level
Determined
by D10-01
30–150 % Page 168
L03-11 OV Inhibit Sel 0 0, 1 - Page 168
L03-17 DC Bus Reg Level
230 V: 375
460 V: 750
575 V: 930
230 V: 150–400
460 V: 300–800
575 V: 431–1150
VDC Page 168
L03-20 DC Bus P Gain A01-02 0.00–5.00 - Page 168
L03-21 Acc/Dec P Gain A01-02 0.10–10.00 sec Page 168
L03-23 CHP Stall P Sel 0 0, 1 - Page 168
L03-24 Mtr Accel Time O02-04 0.001–10.000 sec Page 168
L04-01 Spd Agree Level 0.0 0.0–150.0 Hz Page 170
L04-02 Spd Agree Width 2.0 0.0–20.0 Hz Page 170
L04-03 Spd Agree Lvl+- 0.0 -150.0–150.0 Hz Page 170
L04-04 Spd Agree Wdth+- 2.0 0.0–20.0 Hz Page 170
Parameter Parameter Name Default Range Units Reference
