Man B&W S80ME-C7

MAN Diesel 4.09
Page  of 3
MAN Diesel
198 42 091.4MAN B&W 98 → 50 MC/MCC, 108 → 50 ME/MEC, 70 → 60
MEGI, 50 → 35 MEB
L27/38 GenSet Data
Bore: 270 mm Stroke: 380 mm
Power layout
720 r/min 60 Hz 750 r/min 50 Hz
Eng. kW Gen. kW Eng. kW Gen. kW
5L27/38 ,500 ,440 ,600 ,536
6L27/38 ,980 ,900 ,980 ,900
7L27/38 2,30 2,28 2,30 2,28
8L27/38 2,640 2,534 2,640 2,534
9L27/38 2,970 2,85 2,970 2,85
178 23 079.0
No. of Cyls. A (mm) * B (mm) * C (mm) H (mm)
**Dry weight
GenSet (t)
5 (720 r/min) 4,346 2,486 6,832 3,705 42.3
5 (750 r/min) 4,346 2,486 6,832 3,705 42.3
6 (720 r/min) 4,79 2,766 7,557 3,705 45.8
6 (750 r/min) 4,79 2,766 7,557 3,77 46.
7 (720 r/min) 5,236 2,766 8,002 3,77 52.
7 (750 r/min) 5,236 2,766 8,002 3,77 52.
8 (720 r/min) 5,68 2,986 8,667 3,77 56.3
8 (750 r/min) 5,68 2,986 8,667 3,77 58.3
9 (720 r/min) 6,26 2,986 9,2 3,797 63.9
9 (750 r/min) 6,26 2,986 9,2 3,797 63.9
Fig. 4.09.01: Power and outline of L27/38
P Free passage between the engines, width 600 mm and height 2,000 mm
Q Min. distance between engines: 2,900 mm (without gallery) and 3,00 mm (with gallery)
* Depending on alternator
** Weight includes a standard alternator
All dimensions and masses are approximate and subject to change without prior notice.
178 33 898.2
A
C
B
H
,480
P
Q
,770
,285
