MAN B&W 19.02
Page  of 
MAN Diesel
MAN B&W MC/MCC, ME/ME-B/MEC/MEGI engines 198 45 169.2
Note: All paints are to be of good quality. Paints according to builder‘s standard may be used provided they at least
full the above requirements.
The data stated are only to be considered as guidelines. Preparation, number of coats, lm thickness per coat,
etc. have to be in accordance with the paint manufacturer’s specications.
178 30 207.4
Specication for painting of main engine
Fig. 19.02.01: Painting of main engine: 4 81 101, 4 81 102 or 4 81 103
Components to be painted before
shipment from workshop
Type of paint
No. of coats/
Total dry lm
thickness
µm
Colour:
RAL 840HR
DIN 664
MUNSELL
Component/surfaces, inside engine,
exposed to oil and air
. Unmachined surfaces all over. However
cast type crankthrows, main bearing cap,
crosshead bearing cap, crankpin bearing
cap, pipes inside crankcase and chainwheel
need not to be painted but the cast surface
must be cleaned of sand and scales and
kept free of rust.
Engine alkyd primer, weather
resistant
2/80
Free
Oil and acid resistant alkyd paint.
Temperature resistant to mini-
mum 80 °C.
/30
White:
RAL 900
DIN N:0:0.5
MUNSELL N9.5
Components, outside engine
2. Engine body, pipes, gallery, brackets etc.
Delivery standard is in a primed and nally
painted condition, unless otherwise stated
in the contract.
Engine alkyd primer, weather
resistant.
2/80
Free
Final alkyd paint resistant to salt
water and oil, option: 4 8 03.
/30 Light green:
RAL 609
DIN 23:2:2
MUNSELL0GY 8/4
Heat affected components:
3. Supports for exhaust receiver
Scavenge airpipe outside.
Air cooler housing inside and outside.
Paint, heat resistant to minimum
200 °C.
2/60 Alu:
RAL 9006
DIN N:0:2
MUNSELL N7.5
Components affected by water and
cleaning agents
4. Scavenge air cooler box inside. protection of the components
exposed to moderately to
severely corrosive environment
and abrasion.
2/75
Free
5. Gallery plates topside. Engine alkyd primer, weather
resistant.
2/80
Free
6. Purchased equipment and instruments
painted in makers colour are acceptable
unless otherwise stated in the contract.
Tools
Unmachined surfaces all over on handtools
and lifting tools.
Purchased equipment painted in makers
colour is acceptable, unless otherwise
stated in the contract/drawing.
Oil resistant paint. 2/60 Orange red:
RAL 2004
DIN:6:7:2
MUNSELL N7.5r 6/2
Tool panels
Oil resistant paint. 2/60 Light grey:
RAL 7038
DIN:24::2
MUNSELL N7.5
