Man B&W S80ME-C7 User Manual

S80ME-C 198 43 47-9.1
MAN B&W Diesel A/S 6.03
Page 2 of 3
List of capacities, S80ME-C, High efficiency T/C and central cooling water system
,
PumpsCoolers
Fig. 6.03.02: High efficiency turbocharger and central cooling water system stated at the nominal MCR power (L
1
)
for engines complying with IMO’s NO
x
emission limitations
Cyl. 6 7 8
Nominal MCR at 76.0 r/min kW 23,280 27,160 31,040
Fuel oil circulating pump m
3
/h 9.1 10.7 12.2
Fuel oil supply pump m
3
/h 5.7 6.7 7.6
Jacket cooling pump m
3
/h 1) 200 230 265
2) 215 250 285
3) 200 230 265
4) 200 230 265
Central cooling pump* m
3
/h 1) 550 650 740
2) 570 660 750
3) 560 650 750
4) 550 650 740
Seawater cooling pump* m
3
/h 1) 700 820 940
2) 720 830 950
3) 710 820 950
4) 700 820 940
Main lubricating oil pump* m
3
/h 1) 440 510 590
2) 445 520 590
3) 440 520 590
4) 440 510 590
Scavenge air cooler(s):
Heat dissipation approx. kW 9,090 10,610 12,120
Seawater flow m
3
/h 306 357 408
Lubricating oil cooler:
Heat dissipation approx.* kW 1) 1,750 2,090 2,410
2) 1,880 2,150 2,410
3) 1,810 2,130 2,510
4) 1,770 2,090 2,410
Lubricating oil flow See above ‘Main lubricating oil pump’
Central cooling water flow m
3
/h 1) 244 293 332
2) 264 303 342
3) 254 293 342
4) 244 293 332
Jacket water cooler:
Heat dissipation approx. kW 1) 3,430 4,000 4,580
2) 3,590 4,160 4,730
3) 3,430 4,000 4,580
4) 3,430 4,000 4,580
Jacket cooling water flow See above ‘Jacket cooling water’
Central cooling water flow See above ‘Central cooling water quantity’ for lube oil
Central cooler:
Heat dissipation approx.* kW 1) 14,270 16,700 19,110
2) 14,560 16,920 19,260
3) 14,330 16,740 19,210
4) 14,290 16,700 19,110
Central cooling water flow See above ‘Central cooling water pump’
Seawater flow See above ‘Seawater cooling pump’
Fuel oil heater kW 240 280 320
Exhaust gas amount at 245º C** kg/h 216,000 252,000 288,000
Air consumption kg/h 58.9 68.7 78.6
