198 42 054.4MAN B&W 80 → 26 MC/MCC, 80 → 50 ME/MEC,
70 → 60 MEGI/50 → 35 ME-B
L16/24 GenSet Data
Bore: 160 mm Stroke: 240 mm
Power layout
1,200 r/min 60 Hz 1,000 r/min 50 Hz
Eng. kW Gen. kW Eng. kW Gen. kW
5L6/24 500 475 450 430
6L6/24
660 625 540 55
7L6/24
770 730 630 600
8L6/24
880 835 720 685
9L6/24
990 940 80 770
No. of Cyls. A (mm) * B (mm) * C (mm) H (mm)
**Dry weight
GenSet (t)
5 (,000 r/min) 2,75 ,400 4,5 2,226 9.5
5 (,200 r/min) 2,75 ,400 4,5 2,226 9.5
6 (,000 r/min) 3,026 ,490 4,56 2,226 0.5
6 (,200 r/min) 3,026 ,490 4,56 2,226 0.5
7 (,000 r/min) 3,30 ,585 4,886 2,226 .4
7 (,200 r/min) 3,30 ,585 4,886 2,266 .4
8 (,000 r/min) 3,576 ,680 5,256 2,266 2.4
8 (,200 r/min) 3,576 ,680 5,256 2,266 2.4
9 (,000 r/min) 3,85 ,680 5,53 2,266 3.
9 (,200 r/min) 3,85 ,680 5,53 2,266 3.
178 23 031.0
P Free passage between the engines, width 600 mm and height 2,000 mm
Q Min. distance between engines: ,800 mm
* Depending on alternator
** Weight incl. standard alternator (based on a Leroy Somer alternator)
All dimensions and masses are approximate and subject to change without prior notice.
178 33 874.3
Fig. 4.06.01: Power and outline of L16/24
A
C
B
H
P
Q
830 000
