MAN Diesel
198 42 066.4MAN B&W 80 → 26 MC/MCC, 80 → 50 ME/MEC, 70
→ 60 MEGI, 50 → 35 MEB
L21/31 GenSet Data
Bore: 210 mm Stroke: 310 mm
Power layout
900 r/min 60 Hz 1,000 r/min 50 Hz
Eng. kW Gen. kW Eng. kW Gen. kW
5L2/3 ,000 950 ,000 950
6L2/3 ,320 ,254 ,320 ,254
7L2/3 ,540 ,463 ,540 ,463
8L2/3 ,760 ,672 ,760 ,672
9L2/3 ,980 ,88 ,980 ,88
178 23 043.2
Fig. 4.07.01: Power and outline of L21/31
0


(
1
!
"
#
P Free passage between the engines, width 600 mm and height 2000 mm.
Q Min. distance between engines: 2400 mm (without gallery) and 2600 mm (with galley)
* Depending on alternator
** Weight incl. standard alternator (based on a Uljanik alternator)
All dimensions and masses are approximate, and subject to changes without prior notice.
Cyl. no A (mm) * B (mm) * C (mm) H (mm)
**Dry weight
GenSet (t)
5 (900 rpm) 3,959 ,820 5,680 3,80 2.5
5 (000 rpm)
3,959 ,870 5,730 3,80 2.5
6 (900 rpm) 4,34 ,870 6,086 3,80 23.7
6 (000 rpm) 4,34
2,000 6,26 3,80 23.7
7 (900 rpm) 4,669 ,970 6,760 3,80 25.9
7 (000 rpm)
4,669 ,970 6,537 3,80 25.9
8 (900 rpm) 5,024 2,250 7,20 3,287 28.5
8 (000 rpm)
5,024 2,250 7,76 3,287 28.5
9 (900 rpm) 5,379 2,400 7,660 3,287 30.9
9 (000 rpm)
5,379 2,400 7,660 3,287 30.9
