MAN B&W 18.04
Page 6 of 7
MAN Diesel
MAN B&W ME/MEC/MEGI/ME-B engines 198 45 838.4
Slow down for UMS – Class and MAN Diesel requirements
Table 18.04.03: Slow down functions for UMS
ABS
BV
CCS
DNV
GL
KR
LR
NK
RINA
RS
IACS
MAN Diesel
Sensor and
function Point of location
TE 806 YH Thrust bearing segment
* PT 808 YL Lubricating oil inlet to main engine
TE 82 YH Lubricating oil inlet to main engine
TE 83 YH Piston cooling oil outlet/cylinder
FS 84 YL Piston cooling oil outlet/cylinder
TE 823 YH Main bearing oil outlet temperature/main bearing
(S40/35ME-B9 only)
XC 826 YH Bearing wear (All except S40/35ME-B9)
PT 840 YL Jacket cooling water inlet
TE 8408 YH Jacket cooling water outlet, cylinder/cylinder
TE 8609 YH Scavenge air receiver
TE 860 YH Scavenge air box re-alarm, cylinder/cylinder
TC 870 YH Exhaust gas before turbocharger/turbocharger
TC 8702 YH Exhaust gas after exhaust valve, cylinder/cylinder
TC 8702 YH Exhaust gas after exhaust valve, cylinder/cylinder,
deviation from average
WT 882 YH Axial vibration monitor 2)
* XS 883 YH Oil mist in crankcase/cylinder
Indicates that the sensor is required.
The sensors in the MAN Diesel column are included for Unattended Machinery Spaces (UMS), option: 4 75 27,
subject to class requirements and will be nally specied in the Guidance Values Automation for the specic
engine plant.
The sensor identication codes and functions are listed in Table 8.07.0.
The tables are liable to change without notice, and are subject to latest class requirements.
2) Required for: K-ME-C6/7 and K98ME6/7 engines with and 4 cylinders.
S-ME-C7/8, S-ME-GI7/8, and L-ME-C7/8 engines with 5 and 6 cylinders.
S-ME-B8/9 engines with 5 and 6 cylinders mainly.
(For K90ME9, K/S-ME-C9, and S50ME-B9 data is available on request).
Select one of the alternatives * Or shut down
Or alarm for low ow * Or shut down
Or alarm for overheating of main, crank and crosshead bearings, option: 4 75 34.
See also Table 8.04.04: Shut down functions for AMS and UMS
