MAN B&W 18.06
Page of 5
MAN Diesel
MAN B&W ME/MEC/MEGI/ME-B engines 198 45 875.5
Drain Box for Fuel Oil Leakage Alarm
Any leakage from the fuel oil high pressure pipes
of any cylinder is drained to a common drain box
tted with a level alarm. This is included for both
AMS and UMS.
Bearing Condition Monitoring
Based on our experience we decided in 990
that all plants, whether constructed for Attended
Machinery Space (AMS) or for Unattended Ma-
chinery Space (UMS), must include an oil mist de-
tector specied by MAN Diesel. Since then an Oil
Mist Detector (OMD) and optionally some extent
of Bearing Temperature Monitoring (BTM) equip-
ment have made up the warning arrangements for
prevention of crankcase explosions on two-stroke
engines. Both warning systems are approved by
the classication societies.
In order to achieve a response to damage faster
than possible with Oil Mist Detection and Bearing
Temperature Monitoring alone we introduce Bear-
ing Wear Monitoring (BWM) systems. By monitor-
ing the actual bearing wear continuously, mechani-
cal damage to the crank-train bearings (main-,
crank- and crosshead bearings) can be predicted
in time to react and avoid damaging the journal
and bearing housing.
If the oil supply to a main bearing fails, the bearing
temperature will rise and in such a case a Bear-
ing Temperature Monitoring system will trigger
an alarm before wear actually takes place. For
that reason the ultimate protection against severe
bearing damage and the optimum way of provid-
ing early warning, is a combined bearing wear and
temperature monitoring system.
For all types of error situations detected by the
different bearing condition monitoring systems
applies that in addition to damaging the compo-
nents, in extreme cases, a risk of a crankcase
explosion exists.
Oil Mist Detector
The oil mist detector system constantly measures
samples of the atmosphere in the crankcase com-
partments and registers the results on an opti-
cal measuring track, where the opacity (degree
of haziness) is compared with the opacity of the
atmospheric air. If an increased difference is re-
corded, a slow down is activated (a shut down in
case of Germanischer Lloyd).
Furthermore, for shop trials only MAN Diesel re-
quires that the oil mist detector is connected to
the shut down system.
Four alternative oil mist detectors are available:
Diagrams of the two of them are shown for refer-
ence in Figs. 8.06.0a and 8.06.0b.
Other Alarm Functions
4 75 6 Oil mist detector Graviner MK6.
Make: Kidde Fire Protection
4 75 63 Oil mist detector Visatron VN 25/93.
Make: Schaller Automation
4 75 65
Oil mist detector QMI.
Make: Quality Monitoring Instruments Ltd
4 75 66
Oil mist detector MD-SX.
Make: Daihatsu Diesel Mfg. Co., Ltd
