MAN Diesel
MAN B&W S80MC-C/ME-C7/8, S80MC6
198 43 08-5.1
The stated kW at the generator terminals is available between 70% and 00% of the engine speed at specied MCR
Space requirements have to be investigated case by case on plants with 2600 kW generator.
Dimension H: This is only valid for A. van Kaick generator type DSG, enclosure IP23,
frequency = 60 Hz, speed = 800 r/min
Fig. 4.02.01: Space requirement for side mounted generator PTO/RCF type BWlll S80C/RCF
178 36 29-6.1
&
$
!
"
#
(
'
3
kW generator
700 kW 1200 kW 1800 kW 2600 kW
A 3,396 3,396 3,536 3,536
B 747 747 747 747
C 4,056 4,056 4,336 4,336
D 4,450 4,450 4,730 4,730
F ,797 ,97 2,037 2,47
G 2,890 2,890 3,290 3,290
H ,603 2,0 2,445 3,770
S 390 480 520 660
System mass (kg) with generator:
3,750 36,500 49,600 66,550
System mass (kg) without generator:
29,750 33,850 45,300 6,350
