MAN Diesel
198 42 101.4MAN B&W 98 → 50 MC/MCC, 108 → 50 ME/MEC,
70 → 60 MEGI, 50 → 35 MEB
L28/32H GenSet Data
Bore: 280 mm Stroke: 320 mm
Power layout
720 r/min 60 Hz 750 r/min 50 Hz
Eng. kW Gen. kW Eng. kW Gen. kW
5L28/32H ,050 ,000 ,00 ,045
6L28/32H ,260 ,200 ,320 ,255
7L28/32H ,470 ,400 ,540 ,465
8L28/32H ,680 ,600 ,760 ,670
9L28/32H ,890 ,800 ,980 ,880
178 23 092.0
No. of Cyls. A (mm) * B (mm) * C (mm) H (mm)
**Dry weight
GenSet (t)
5 (720 r/min) 4,279 2,400 6,679 3,84 32.6
5 (750 r/min) 4,279 2,400 6,679 3,84 32.6
6 (720 r/min) 4,759 2,50 7,269 3,84 36.3
6 (750 r/min) 4,759 2,50 7,269 3,84 36.3
7 (720 r/min) 5,499 2,680 8,79 3,374 39.4
7 (750 r/min) 5,499 2,680 8,79 3,374 39.4
8 (720 r/min) 5,979 2,770 8,749 3,374 40.7
8 (750 r/min) 5,979 2,770 8,749 3,374 40.7
9 (720 r/min) 6,99 2,690 8,889 3,534 47.
9 (750 r/min) 6,99 2,690 8,889 3,534 47.
P Free passage between the engines, width 600 mm and height 2,000 mm
Q Min. distance between engines: 2,655 mm (without gallery) and 2,850 mm (with gallery)
* Depending on alternator
** Weight includes a standard alternator, make A. van Kaick
178 33 921.3
Fig. 4.10.01: Power and outline of L28/32H
A
C
B
H P
,490
Q
,800
,26
