Man B&W S80ME-C7 User Manual

S80ME-C 198 39 38-2.3
MAN B&W Diesel A/S 17.07
Page 1 of 1
Fig. : 17.07.01
No. of cyl. 6 7 8
Firing sequence : 1-5-3-4-2-6 1-7-2-5-4-3-6 1-8-3-4-7-2-5-6
External Forces and Moments, S80ME-C, Layout point L
1
- SFOC
a) 1st order moments are as standard, balanced so as to obtain equal values for horizontal and vertical
moments for all cylinder numbers.
c) 4,5 and 6 -cylinder engines can be fitted with 2nd order moment compensators on the aft and fore end,
reducing the 2nd order external moment.
External forces [kN] :
1. Order : Horizontal. 0 0 0
1. Order : Vertical. 0 0 0
2. Order : Vertical 0 0 0
4. Order : Vertical 0 0 0
6. Order : Vertical 20 0 0
External moments [kNm] :
1. Order : Horizontal. a) 0 252 846
1. Order : Vertical. a) 0 252 846
2. Order : Vertical 3,401 c) 987 0
4. Order : Vertical 229 652 265
6. Order : Vertical 0 1 0
Guide force H-moments in [kNm] :
1 x No. of cyl. 2,180 1,597 1,150
2 x No. of cyl. 130 - -
3 x No. of cyl. - - -
Guide force X-moments in [kNm] :
1. Order : 0 208 699
2. Order : 629 183 0
3. Order : 1,134 1,241 1,590
4. Order : 993 2,821 1,146
5. Order : 0 262 3,284
6. Order : 0 42 0
7. Order : 0 0 89
8. Order : 216 17 0
9. Order : 298 33 30
10. Order : 67 189 0
11. Order : 0 126 161
12. Order : 0 9 38
