Man B&W S80ME-C7

MAN Diesel 4.06
Page 3 of 3
MAN Diesel
198 42 054.4MAN B&W 80 → 26 MC/MCC, 80 → 50 ME/MEC,
70 → 60 MEGI/50 → 35 ME-B
Cyl. 5 6 7 8 9
Max continues rating 1,200 rpm
kW 500 660 770 880 990
Engine driven pumps:
LT cooling water pump 2 bar m³/h 27 27 27 27 27
HT cooling water pump 2 bar m³/h 27 27 27 27 27
Lubricating oil main pump 8 bar m³/h 2 2 35 35 35
Separate pumps:
Max. Delivery pressure of cooling water pumps bar 2.5 2.5 2.5 2.5 2.5
Diesel oil pump (5 bar at fuel oil inlet A) m³/h 0.35 0.46 0.54 0.6 0.69
Fuel oil supply pump (4 bar discharge pressure) m³/h 0.7 0.22 0.26 0.30 0.34
Fuel oil circulating pump (8 bar at fuel oil inlet A) m³/h 0.35 0.46 0.54 0.62 0.70
Cooling capacity:
Lubricating oil kW 79 03 22 40 59
Charge air LT kW 40 57 70 82 95
Total LT system kW 9 60 92 222 254
Flow LT at 36°C inlet and 44°C outlet m³/h 3 7 2 24 27
Jacket cooling kW 9 62 9 220 249
Charge air HT kW 23 69 90 2 230
Total HT system kW 242 33 38 43 479
Flow HT at 44°Cinlet and 80°C outlet m³/h 6 8 9 0 
Total from engine kW 36 49 573 653 733
LT ow at 36°C inlet m³/h 3 7 2 24 27
LT temp. Outlet engine
(at 36°C and  string cooling water system)
°C 60 6 60 60 59
Gas Data:
Exhaust gas ow kg/h 3,400 4,600 5,500 6,200 7,000
Exhaust gas temp. °C 330 340 340 340 340
Max. Allowable back press. bar 0.025 0.025 0.025 0.025 0.025
Air consumption kg/h 3,280 4,500 5,300 6,000 6,800
Starting Air System:
Air consumption per start Nm 0.47 0.56 0.65 0.75 0.84
Air consumption per start Nm 0.80 0.96 .2 .28 .44
Heat Radiation:
Engine kW 9 3 5 8 2
Alternator kW (see separate data from the alternator maker)
The stated heat balances are based on tropical conditions.The exhaust gas data (exhaust gas ow, exhaust gas temp.
and air consumption). are based on ISO ambient condition.
* The outlet temperature of the HT water is xed to 80°C, and 44°C for the LT water
At different inlet temperature the ow will change accordingly.
Example: If the inlet temperature is 25°C then the LT ow will change to (44-36)/(44-25)*00 = 42% of the original ow.
If the temperature rises above 36°C, then the L.T. outlet will rise acordingly.
L16/24 GenSet Data
Fig. 4.06.02b: List of capacities for L16/24 1,200 rpm
