Man B&W S80ME-C7 User Manual

S/K80ME-C 198 42 14-9.0
MAN B&W Diesel A/S 19.10
Page 5 of 8
1 905 Lifting tool for crankshaft 136 240 1200 360
2 905 Lifting tool for thrust shaft 66 260 1500 140
3 906 Pin gauge for crank shaft top dead centre 2 740 321 106
4 915 Support for tilting tool 16 n.a. n.a. n.a. 650 140
Pos Sec. Description
Mass Dimensions (mm)
(kg)
ABCDE
Fig. 19.10.03: Dimensions and masses of tools
B
A
C
1
3 4
2
178 51 29-8.0
178 51 26-2.0
178 51 28-6.0
178 51 33-3.0
