Man B&W S80ME-C7 - Page 336

S/K80ME-C 198 42 14-9.0
MAN B&W Diesel A/S 19.10
Page 8 of 8
1 913 Pump for hydraulic jacks (max. dimensions) 55 500 390 595
2 Box with hydraulic jacks (max. dimensions) 290 1020 260
Pos Sec. Description
Mass Dimensions (mm)
(kg)
ABCDE
Fig. 19.10.06: Dimensions and masses of tools
A
B
C
1 2
178 51 38-2.0178 51 37-0.0
