MAN B&W 4.03
Page  of 6
MAN Diesel
198 43 156.2MAN B&W K108ME-C6, K98MC/MC-C/ME/ME-C6/7,
S90MC-C/ME-C7/8, K90ME/ME-C9, K90MC-C/ME-C6, S80MC6,
S80MC-C7/8, S80ME-C7/8/9, K80ME-C9, K80MC-C/ME-C6,
S70MCC/ME-C/ME-GI7/8, S70MC6, L70MCC/ME-C7/8,
S65ME-C/ME-GI8, S60MC6, S60MC-C/ME-C/ME-GI7/8,
L60MC-C/ME-C7/8, S50MC-C7/8, S50MC6, S50ME-B8/9
Pos.

Special face on bedplate and frame box

Ribs and brackets for supporting the face and machined blocks for alignment of gear or stator housing
3 Machined washers placed on frame box part of face to ensure that it is ush with the face on the bedplate
4 Rubber gasket placed on frame box part of face
5 Shim placed on frame box part of face to ensure that it is ush with the face of the bedplate
6 Distance tubes and long bolts
7 Threaded hole size, number and size of spring pins and bolts to be made in agreement with PTO maker
8 Flange of crankshaft, normally the standard execution can be used
9 Studs and nuts for crankshaft ange
0
Free ange end at lubricating oil inlet pipe (incl. blank ange)
 Oil outlet ange welded to bedplate (incl. blank ange)
 Face for brackets
3
Brackets
4
Studs for mounting the brackets
5
Studs, nuts and shims for mounting of RCF/generator unit on the brackets
6
Shims, studs and nuts for connection between crankshaft gear and RCF/generator unit
7
Engine cover with connecting bolts to bedplate/frame box to be used for shop test without PTO
8
Intermediate shaft between crankshaft and PTO
9
Oil sealing for intermediate shaft
0
Engine cover with hole for intermediate shaft and connecting bolts to bedplate/frame box
 Plug box for electronic measuring instrument for checking condition of axial vibration damper
 Tacho encoder for ME control system or Alpha lubrication system on MC engine
3
Tacho trigger ring for ME control system or Alpha lubrication system on MC engine
Pos. no:   3 4 5 6 7 8 9 0   3 4 5 6 7 8 9 0   3
BWIII/RCF A A A A B A B A A A A A B B A A A
BWIII/CFE A A A A B A B A A A A A B B A A A
BWII/RCF A A A A A A A
BWII/CFE A A A A A A A
BWI/RCF A A A A B A B A A A
BWI/CFE A A A A B A B A A A A A
DMG/CFE A A A B C A B A A A
A: Preparations to be carried out by engine builder
B: Parts supplied by PTOmaker
C: See text of pos. no.
178 89 342.0
Fig. 4.03.01b: Engine preparations for PTO
