Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
PC: IP address mode
111 016
1: DHCP
[spacer]
Setting of the method how the IP address of the Ethernet interface of the
processor module shall be defined.
DHCP: The IP address shall be retrieved from a DHCP server.
Fix: The setting of PC: IP address shall be used.
Device address: The setting of PC: IP address shall be used for the
first three number values of the IP address, the fourth number value of the
IP address shall be the value of PC: Device address.
[spacer]
PC: IP Enable config.
111 017
0: don't execute
[spacer]
Activating the Ethernet interface of the processor module.
[spacer]
PC: Delta f
003 057
2.0 0.0 2.0 %fnom Fig. 3-5, (p. 3-9)
[spacer]
The measured frequency value is transmitted via the PC interface if it differs by
the set delta from the last measured value transmitted.
[spacer]
PC: Delta meas.v.ILS tel
003 155
3.0 0.0 15.0 Fig. 3-5, (p. 3-9)
[spacer]
The telegram is transmitted if a measured value differs by the set delta quantity
from the last measured value transmitted.
[spacer]
PC: Delta t
003 058
1 0 15 min Fig. 3-5, (p. 3-9)
[spacer]
All measured values are transmitted again via the PC interface after this time
period has elapsed – provided that transmission has not been triggered by the
other delta conditions.
[spacer]
PC: Time-out
003 188
1 1 60 min Fig. 3-5, (p. 3-9)
[spacer]
Setting for the time to elapse after the last telegram exchange via the PC
interface before activating the second communication channel of
communication module A.
P634 7 Settings
7-16 P634/EN M/R-42-A // P634311653
