Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
COMM1: Pos. acknowledgement
103 060
1: Single character E5
[spacer]
The following transmission frame formats are available (according to the
standard):
Short message FT 1.2: short message with a fixed block length of 5
characters
Single character E5: single control character
[spacer]
COMM1: Address mode
003 168
1: Physical
[spacer]
Setting for the address mode.
[spacer]
COMM1: Test monitor on
003 166
0: No Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
Fig. 3-10, (p. 3-15)
Fig. 3-11, (p. 3-16)
Fig. 3-12, (p. 3-17)
[spacer]
Setting specifying whether data shall be recorded for service activities.
[spacer]
COMM1: Name of manufacturer
003 161
1: SE Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
[spacer]
Setting for the name of the manufacturer.
Note:
This setting can be changed to ensure compatibility.
This setting is hidden unless an IEC 870-5 protocol is enabled.
[spacer]
COMM1: Octet address ASDU
003 073
1 0 255 Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
[spacer]
The communication address and the ASDU address are used to identify the
device in communication via the interface. An identical setting must be selected
for both addresses.
Note: This setting is hidden unless an IEC 870-5 protocol is enabled.
“ASDU”: Application Service Data Unit
P634 7 Settings
7-20 P634/EN M/R-42-A // P634311653
