Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
COMM1: Spontan. sig. enable
003 177
65535: All Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
[spacer]
Enable for the transmission of spontaneous signals via the communication
interface.
Note: This setting is hidden unless an IEC 870-5 protocol is enabled.
[spacer]
COMM1: Select. spontan.sig.
003 179
060 000: MAIN: Without function Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
[spacer]
Selection of spontaneous signals for transmission via “logical” communication
interface 1.
[spacer]
COMM1: Transm.enab.cycl.dat
003 074
0: Without Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
[spacer]
Enabling of cyclic transmission of measured values via the communication
interface.
Note: This setting is hidden unless an IEC 870-5 protocol is enabled.
[spacer]
COMM1: Cycl. data ILS tel.
003 175
060 000: MAIN: Without function Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
[spacer]
Selection of the measured values that are transmitted in a user-defined
telegram via the communication interface.
Note: This setting is hidden unless an IEC 870-5 protocol is enabled.
[spacer]
COMM1: Delta V
003 050
3.0 0.0 15.0 %Vnom Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
[spacer]
A measured voltage value is transmitted via the communication interface if it
differs by the set delta quantity from the last measured value transmitted.
Note: This setting is hidden unless an IEC 870-5 protocol is enabled.
[spacer]
COMM1: Delta I
003 051
3.0 0.0 15.0 %Inom Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
[spacer]
A measured current value is transmitted via the communication interface if it
differs by the set delta quantity from the last measured value transmitted.
Note: This setting is hidden unless an IEC 870-5 protocol is enabled.
