Micom P634 - Page 414

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MEASO: BCD-Out max. value
037 143
399 0 399
[spacer]
The variable Mx is to be issued in BCD form.
For measured values in the range “measured values to be issued” the output
value should change linearly with the measured value.
●
Range of measured values for the variable Mx: Mx,RL1 ... Mx,RL2
●
Range of associated scaled measured values: 0 ... 1
●
Range of measured values to be issued: Mx,min ... Mx,max
●
Range of scaled measured values to be issued: Mx,scal,min ... Mx,scal,max
●
Designation of the set values in the data model: “Scaled min. val. BCD” ...
“Scaled max. val. BCD”
with:
Mx,scal,min = (Mx,min - Mx,RL1)/(Mx,RL2 - Mx,RL1)
Mx,scal,max = (Mx,max - Mx,RL1)/(Mx,RL2 - Mx,RL1)
BCD display values for measured values in the range “measured values to be
issued”; range: “BCD-Out min. value” ... “BCD-Out max. value”
BBCD display values for measured values ≤ Mx,min; range: “BCD-Out min.
value”
BCD display values for measured values ≥ Mx,max; range: “BCD-Out max.
value”
[spacer]
MEASO: Fct. assignm. A-1
053 000
060 000: MAIN: Without function Fig. 3-36, (p. 3-58)
[spacer]
MEASO: Fct. assignm. A-2
053 001
060 000: MAIN: Without function
[spacer]
Selection of the measured value to be transmitted in analog form.
[spacer]
MEASO: Hold time output A-1
010 114
0.10 0.10 10.00 s Fig. 3-36, (p. 3-58)
[spacer]
MEASO: Hold time output A-2
010 115
0.10 0.10 10.00 s
[spacer]
Setting for the time delay for output of the selected measured value.
[spacer]
MEASO: Scaled min. val. A-1
037 104
0.000 0.000 1.000 Fig. 3-36, (p. 3-58)
[spacer]
MEASO: Scaled knee val. A-1
037 105
Blocked 0.000 1.000 Fig. 3-36, (p. 3-58)
[spacer]
MEASO: Scaled max. val. A-1
037 106
1.000 0.000 1.000 Fig. 3-36, (p. 3-58)
[spacer]
MEASO: Scaled min. val. A-2
037 110
0.000 0.000 1.000
P634 7 Settings
7-60 P634/EN M/R-42-A // P634‑311‑653
