Parameter Address
Default Min Max Unit Logic Diagram
Parameter subset
selection
PSS: Control via USER
003 100
0: No Fig. 3-69, (p. 3-101)
[spacer]
If parameter subset selection is to be handled from the integrated local control
panel rather than via binary signal inputs, choose the setting Yes.
[spacer]
PSS: Param.subs.sel. USER
003 060
1: Parameter subset 1 Fig. 3-69, (p. 3-101)
[spacer]
Selection of the parameter subset from the local control panel.
[spacer]
PSS: Keep time
003 063
Blocked 0.000 65.000 s Fig. 3-69, (p. 3-101)
[spacer]
The setting of this timer stage is relevant only if parameter subset selection is
carried out via the binary signal inputs. Any voltage-free pause that may occur
during selection is bridged. If, after this time period has elapsed, no binary
signal input has yet been set, then the parameter subset selected from the local
control panel shall apply.
Parameter Address
Default Min Max Unit Logic Diagram
Self-monitoring
SFMON: Fct. assign. warning
021 030
060 000: MAIN: Without function Fig. 3-70, (p. 3-102)
[spacer]
Selection of the signals whose appearance shall result in the signals “Warning
(LED)” and “Warning (relay)” and in the activation of the LED indicator labeled
“ALARM”. Signals caused by faulty hardware and leading to blocking of the
device are not configurable. They always result in the above signals and
indication.
[spacer]
SFMON: Mon.sig. retention
021 018
Blocked 0 240 h
[spacer]
This setting defines the duration (in hours) for which a device-internal fault is
stored, so that a decision may be taken between an automatic warm restart and
an automatic device blocking. (Setting to Blocked may be considered the same
as unlimited storage.)
P634 7 Settings
7-82 P634/EN M/R-42-A // P634‑311‑653
