Micom P634 - Page 455

Parameter Address
Default Min Max Unit Logic Diagram
Limit value
monitoring
LIM_1: General enable USER
014 014
0: No Fig. 3-172, (p. 3-217)
[spacer]
LIM_2: General enable USER
014 015
0: No
[spacer]
LIM_3: General enable USER
014 017
0: No
[spacer]
Enabling or disabling the limit value monitoring function.
[spacer]
LIM_1: Select. meas. input
019 111
0: End a Fig. 3-171, (p. 3-216)
[spacer]
LIM_2: Select. meas. input
019 112
1: End b
[spacer]
LIM_3: Select. meas. input
019 113
2: End c
[spacer]
Selecting a measuring input for limit value monitoring of the measured values.
[spacer]
LIM_1: I>
015 116
1.20 0.20 4.00 Inom Fig. 3-172, (p. 3-217)
[spacer]
LIM_2: I>
016 116
1.20 0.20 4.00 Inom
[spacer]
LIM_3: I>
017 114
1.20 0.20 4.00 Inom
[spacer]
Setting for the operate value of I>.
[spacer]
LIM_1: I>>
015 117
Blocked 0.20 4.00 Inom Fig. 3-172, (p. 3-217)
[spacer]
LIM_2: I>>
016 117
Blocked 0.20 4.00 Inom
[spacer]
LIM_3: I>>
017 117
Blocked 0.20 4.00 Inom
[spacer]
Setting for the operate value of I>>.
[spacer]
LIM_1: tI>
015 120
5 0 100 s Fig. 3-172, (p. 3-217)
[spacer]
LIM_2: tI>
016 120
5 0 100 s
[spacer]
LIM_3: tI>
017 120
5 0 100 s
[spacer]
Setting for the operate delay of I>.
