Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
REF_3: IR,m2 PSx
072 194 073 194 074 194 075 194
1.00 0.10 1.50 Iref
[spacer]
Knee point from which the characteristic runs with a set gradient of m
2
(operating mode 'Low imped. / IP,max').
P634 7 Settings
7-156 P634/EN M/R-42-A // P634‑311‑653
