Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
DTOC3: IN>> dynamic PSx
076 195 077 195 078 195 079 195
1.00 0.10 8.00 Inom
[spacer]
DTOC4: IN>> dynamic PSx
099 156 099 157 099 158 099 159
1.00 0.10 8.00 Inom
[spacer]
Setting for operate value IN>> in dynamic mode. This operate value is only
effective while the hold time for dynamic parameters is elapsing.
[spacer]
DTOC1: IN>>> dynamic PSx
076 156 077 156 078 156 079 156
1.00 0.10 8.00 Inom Fig. 3-111, (p. 3-158)
[spacer]
DTOC2: IN>>> dynamic PSx
076 176 077 176 078 176 079 176
1.00 0.10 8.00 Inom
[spacer]
DTOC3: IN>>> dynamic PSx
076 196 077 196 078 196 079 196
1.00 0.10 8.00 Inom
[spacer]
DTOC4: IN>>> dynamic PSx
099 160 099 161 099 162 099 163
1.00 0.10 8.00 Inom
[spacer]
Setting for operate value IN>>> in dynamic mode. This operate value is only
effective while the hold time for dynamic parameters is elapsing.
[spacer]
DTOC1: tIN> PSx
076 060 077 060 078 060 079 060
1.00 0.00 100.00 s Fig. 3-111, (p. 3-158)
[spacer]
DTOC2: tIN> PSx
076 170 077 170 078 170 079 170
1.00 0.00 100.00 s
[spacer]
DTOC3: tIN> PSx
076 190 077 190 078 190 079 190
1.00 0.00 100.00 s
[spacer]
DTOC4: tIN> PSx
099 100 099 101 099 102 099 103
1.00 0.00 100.00 s
[spacer]
Setting for the operate delay of the IN> stage.
[spacer]
DTOC1: tIN>> PSx
076 061 077 061 078 061 079 061
0.50 0.00 100.00 s Fig. 3-111, (p. 3-158)
[spacer]
DTOC2: tIN>> PSx
076 171 077 171 078 171 079 171
0.50 0.00 100.00 s
[spacer]
DTOC3: tIN>> PSx
076 191 077 191 078 191 079 191
0.50 0.00 100.00 s
[spacer]
DTOC4: tIN>> PSx
099 104 099 105 099 106 099 107
0.50 0.00 100.00 s
[spacer]
Setting for the operate delay of the IN>> stage.
[spacer]
DTOC1: tIN>>> PSx
076 062 077 062 078 062 079 062
0.50 0.00 100.00 s Fig. 3-111, (p. 3-158)
