Micom P634 - Page 518

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
DTOC3: IN> PSx
076 184 077 184 078 184 079 184
0.25 0.10 8.00 Inom
[spacer]
DTOC4: IN> PSx
099 076 099 077 099 078 099 079
0.25 0.10 8.00 Inom
[spacer]
Setting for operate value IN>.
[spacer]
DTOC1: IN>> PSx
076 055 077 055 078 055 079 055
Blocked 0.10 8.00 Inom Fig. 3-111, (p. 3-158)
[spacer]
DTOC2: IN>> PSx
076 165 077 165 078 165 079 165
Blocked 0.10 8.00 Inom
[spacer]
DTOC3: IN>> PSx
076 185 077 185 078 185 079 185
Blocked 0.10 8.00 Inom
[spacer]
DTOC4: IN>> PSx
099 080 099 081 099 082 099 083
Blocked 0.10 8.00 Inom
[spacer]
Setting for operate value IN>>.
[spacer]
DTOC1: IN>>> PSx
076 056 077 056 078 056 079 056
Blocked 0.10 8.00 Inom Fig. 3-111, (p. 3-158)
[spacer]
DTOC2: IN>>> PSx
076 166 077 166 078 166 079 166
Blocked 0.10 8.00 Inom
[spacer]
DTOC3: IN>>> PSx
076 186 077 186 078 186 079 186
Blocked 0.10 8.00 Inom
[spacer]
DTOC4: IN>>> PSx
099 084 099 085 099 086 099 087
Blocked 0.10 8.00 Inom
[spacer]
Setting for operate value IN>>>.
[spacer]
DTOC1: IN> dynamic PSx
076 154 077 154 078 154 079 154
1.00 0.10 8.00 Inom Fig. 3-111, (p. 3-158)
[spacer]
DTOC2: IN> dynamic PSx
076 174 077 174 078 174 079 174
1.00 0.10 8.00 Inom
[spacer]
DTOC3: IN> dynamic PSx
076 194 077 194 078 194 079 194
1.00 0.10 8.00 Inom
[spacer]
DTOC4: IN> dynamic PSx
099 152 099 153 099 154 099 155
1.00 0.10 8.00 Inom
[spacer]
Setting for operate value IN> in dynamic mode. This operate value is only
effective while the hold time for dynamic parameters is elapsing.
[spacer]
DTOC1: IN>> dynamic PSx
076 155 077 155 078 155 079 155
1.00 0.10 8.00 Inom Fig. 3-111, (p. 3-158)
[spacer]
DTOC2: IN>> dynamic PSx
076 175 077 175 078 175 079 175
1.00 0.10 8.00 Inom
P634 7 Settings
7-164 P634/EN M/R-42-A // P634‑311‑653
