Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
DTOC4: Ineg>>> dynamic PSx
099 184 099 185 099 186 099 187
1.00 0.10 8.00 Inom
[spacer]
Setting for operate value Ineg>>> dynamic. (Ineg = negative-sequence current)
This operate value is effective only while the timer stage MAIN: Hold time
dyn.param. is elapsing.
[spacer]
DTOC1: tIneg> PSx
076 203 077 203 078 203 079 203
1.00 0.00 100.00 s Fig. 3-110, (p. 3-156)
[spacer]
DTOC2: tIneg> PSx
076 213 077 213 078 213 079 213
1.00 0.00 100.00 s
[spacer]
DTOC3: tIneg> PSx
076 223 077 223 078 223 079 223
1.00 0.00 100.00 s
[spacer]
DTOC4: tIneg> PSx
099 188 099 189 099 190 099 191
1.00 0.00 100.00 s
[spacer]
Setting for the operate delay of the Ineg> stage.
[spacer]
DTOC1: tIneg>> PSx
076 204 077 204 078 204 079 204
0.50 0.00 100.00 s Fig. 3-110, (p. 3-156)
[spacer]
DTOC2: tIneg>> PSx
076 214 077 214 078 214 079 214
0.50 0.00 100.00 s
[spacer]
DTOC3: tIneg>> PSx
076 224 077 224 078 224 079 224
0.50 0.00 100.00 s
[spacer]
DTOC4: tIneg>> PSx
099 192 099 193 099 194 099 195
0.50 0.00 100.00 s
[spacer]
Setting for the operate delay of the Ineg>> stage.
[spacer]
DTOC1: tIneg>>> PSx
076 205 077 205 078 205 079 205
0.50 0.00 100.00 s Fig. 3-110, (p. 3-156)
[spacer]
DTOC2: tIneg>>> PSx
076 215 077 215 078 215 079 215
0.50 0.00 100.00 s
[spacer]
DTOC3: tIneg>>> PSx
076 225 077 225 078 225 079 225
0.50 0.00 100.00 s
[spacer]
DTOC4: tIneg>>> PSx
099 196 099 197 099 198 099 199
0.50 0.00 100.00 s
[spacer]
Setting for the operate delay of the Ineg>>> stage.
[spacer]
DTOC1: IN> PSx
076 054 077 054 078 054 079 054
0.25 0.10 8.00 Inom Fig. 3-111, (p. 3-158)
[spacer]
DTOC2: IN> PSx
076 164 077 164 078 164 079 164
0.25 0.10 8.00 Inom
