Micom P634 - Page 531

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
V<>: Hyst. V<> meas. PSx
076 048 077 048 078 048 079 048
3 1 10 % Fig. 3-135, (p. 3-183)
[spacer]
Setting for the hysteresis of the trigger stages for monitoring measured
voltages.
