Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Current IY,b prim.
005 132
Not measured 0 65000 A
[spacer]
MAIN: Current IY,c prim.
005 133
Not measured 0 65000 A
[spacer]
Display of the current value as a primary quantity measured by the P634 at the
T14, T24 or T34 transformers.
[spacer]
MAIN: Current IN,d prim.
005 124
Not measured 0 65000 A Fig. 3-48, (p. 3-79)
[spacer]
Display of the residual current calculated by the P634 from the sum of the phase
currents, end a, b, c or d, respectively, as a primary quantity.
[spacer]
MAIN: Voltage V prim.
005 018
Not measured 0.0 2500.0 kV Fig. 3-50, (p. 3-82)
[spacer]
Display of the voltage measured by the P634, as a primary quantity.
[spacer]
MAIN: Curr. IP,max,a p.u.
005 111
Not measured 0.000 25.000 Inom Fig. 3-46, (p. 3-78)
[spacer]
MAIN: Curr. IP,max,b p.u.
005 112
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Curr. IP,max,c p.u.
005 113
Not measured 0.000 25.000 Inom
[spacer]
MAIN: Curr. IP,max,d p.u.
005 116
Not measured 0.000 25.000 Inom
[spacer]
Display of the maximum phase current (of the respective end), referred to I
nom
.
[spacer]
MAIN: IP,max p.u.,delay a
005 163
Not measured 0.000 25.000 Inom Fig. 3-46, (p. 3-78)
[spacer]
MAIN: IP,max p.u.,delay b
006 163
Not measured 0.000 25.000 Inom
[spacer]
MAIN: IP,max p.u.,delay c
007 163
Not measured 0.000 25.000 Inom
[spacer]
MAIN: IP,max p.u.,delay d
008 163
Not measured 0.000 25.000 Inom
[spacer]
Display of the delayed maximum phase current (of the respective end a)
referred to I
nom
.
[spacer]
MAIN: IP,max p.u.,stored a
005 160
Not measured 0.000 25.000 Inom Fig. 3-46, (p. 3-78)
[spacer]
MAIN: IP,max p.u.,stored b
006 160
Not measured 0.000 25.000 Inom
