Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
OL_DA: Offset THRM2 replica
004 192
Not measured -25000 25000 %
[spacer]
Display of the additional reserve if the coolant temperature is taken into
account. This display is relevant if the coolant temperature has been set to a
value below the maximum permissible coolant temperature or, in other words, if
the thermal model has been shifted downwards.
If, on the other hand, the coolant temperature and the maximum permissible
coolant temperature have been set to the same value, then the coolant
temperature is not taken into account and the characteristic is a function of the
current only. The additional reserve amounts to 0 in this case.
[spacer]
OL_DA: Status THRM2 replica
004 185
Not measured 0 250 %
[spacer]
Display of the buffer content of the thermal overload protection function, THRM1
or THRM2.
[spacer]
OL_DA: Load current THRM2
004 189
Not measured 0.00 3.00 Inom
[spacer]
Display of the load current used by the thermal overload protection function,
THRM1 or THRM2, respectively, to calculate the tripping time.
[spacer]
OL_DA: Object temp. THRM2
004 186
Not measured -40 300 °C
[spacer]
Display of the temperature of the protected object.
[spacer]
OL_DA: Pre-trip t.leftTHRM2
004 188
Not measured 0.0 1000.0 min
[spacer]
Display of the time remaining before the thermal overload protection function
will reach the trip threshold.
P634 8 Information and Control Functions
8-164 P634/EN M/R-42-A // P634‑311‑653
