Version Changes
‑411/412
‑652
Release: 2015-06-23
As a variant, the new binary I/O module X(6I 3O) is now
available to provide the power supply module with an
additional 6 binary signal inputs and 3 output relays.
The Redundancy Ethernet Board (REB) can now be
ordered with an additional redundancy protocol: PRP
(Parallel Redundancy Protocol) is available now as an
alternative to RSTP, SHP or DHP.
Diagram
The updated connection diagrams now include the new
binary I/O module X(6I 3O):
●
P634 -411 (for 84 TE case, with pin-terminal
connection)
●
P634 -412 (for 84 TE case, with ring-terminal
connection)
Software
GOOSE The number of GOOSE inputs has been extended to
128:
Extension of available GOOSE inputs from 32× 1-
pole/32× 2-pole to 128 GOOSE inputs configurable in
the IED Configurator tool. Max. 128× 1-pole binary
signals freely configurable in the device or alternatively
up to max. 128× 2-pole switchgear position indications
for using the Control/Interlocking conditions.
The number of GOOSE inputs has been extended to
128:
Extension of available GOOSE inputs from 32× 1-
pole/32× 2-pole to 128 GOOSE inputs configurable in
the IED Configurator tool. Max. 128× 1-pole binary
signals freely configurable in the device or alternatively
up to max. 128× 2-pole switchgear position indications
for using the Control/Interlocking conditions.
GSSE Function group GSSE has been removed. It has been
replaced by the extended GOOSE input option.
IEC
Bug fixing:
●
Required parameters were missing from the set
of available options of IEC: SigGGIO1
selection.
MAIN The maximum values of the measured primary currents
have been increased to 65000 A.
DTOC4 Function group DTOC4 has become available in
addition to DTOC1 … DTOC3. All DTOCx have the same
functionality and can be configured and used
independent of each other.
P634 A5 P634 Version History
A5-34 P634/EN M/R-42-A // P634‑311‑653
