10-15
WARNING
z Improper defibrillation will endanger the patient’s safety. You user should decide
whether to defibrillate the patient based on the patient’s actual condition.
z Before defibrillating the patient, the user should ensure the defibrillator and the
monitor have been tested as a system and the two devices can work together safely
and effectively.
z Before defibrillating the patient, the user should ensure the defibrillator has been
connected to the auxiliary output port of the monitor, the defibrillation
synchronization function is enabled, and the filter mode is set to DIAGNOSTIC.
z When the defibrillation is done, sure to disable the defibrillation function and
select the filter method as needed.
ECG CAL Select this option to begin calibrating the ECG. To stop
calibration, select this option again, or change the ECG lead
selection on the screen.
ADJUST WAVE POS
>>
This is used to adjust the position of the ECG waveform on
the screen. Select this option to access the ADJUST WAVE
POS menu. Open the CH NAME popup menu and select the
channel to be adjusted. Afterwards, select the UP-DOWN
option and rotate the control knob to adjust the position of
the selected channel on the screen. The BACK TO
DEFAULT option allows you to restore the waveform to the
default position on the screen.
Figure 10-11 ADJUST WAVE POS Menu
CONFIG >> You can use this option to access the ECG CONFIG menu.
You may choose the FACTORY CONFIG or the USER
CONFIG. After finishing the selection, a dialog pops up
asking for confirmation of your selection.
To Next Page
