14-5
You can perform the following settings in this menu.
ALM IBP alarm on/off status
ON: When a IBP alarm occurs, the monitor gives alarm
indications and stores the alarm;
OFF: When a IBP alarm occurs, the monitor neither gives
alarm indications nor stores the alarm;
When OFF is selected, the
icon is displayed on the right
of the IBP (1,2) label.
ALM LEV Alarm level
Options: HIGH, MED and LOW.
AMP ADJUST Amplitude adjustment
This option allows you to adjust the waveform amplitude.
Options: MANUAL and AUTO.
1. MANUAL: If MANUAL is selected, you can select an IBP channel manually from the
options, including ART, PA, CVP, RAP, LAP, ICP, P1 and P2, and then adjust the IBP
scale in the SCALE ADJUST >> menu.
2. AUTO: If AUTO is selected, the waveform labels of IBP channels become P1 and P2 and
the IBP scale is adjusted by the system automatically.
SWEEP Waveform speed
Options: 12.5 and 25.0 mm/s.
PR SOUND Pulse volume
Range: 0–10. 0 indicates the volume is closed and 10
indicates the maximum volume.
RESPONSE Options: HIGH, MED and LOW.
The corresponding averaging time is about 1 s, 8 s and 12 s
respectively.
The IBP value displayed on the monitor screen is the average of data collected within a specific
time. The shorter the averaging time is, the quicker the patient monitor responds to changes in the
patient’s blood pressure. Contrarily, the longer the averaging time is, the slower the patient
monitor responds to changes in the patient’s blood pressure, but the measurement accuracy will
be improved. For critically ill patients, selecting shorter averaging time will help understanding
the patient’s state.
IBP1 UNIT Options: mmHg, kPa and cmH2O.
IBP2 UNIT Options: mmHg, kPa and cmH2O.
ALM LIMIT SETUP >> This option allows you to access the following menu,
whereby you can set the upper and lower alarm limits.
