Mindray DPM 4 Operator's Manual

A-16
A.14.2 Oridion CO
2
Specifications
CO2 measurement range 0 to 99mmHg
Precision*
0 to 38 mmHg:
39 to 99 mmHg:
±2 mmHg
±5% + 0.08% × (reading - 38 mmHg)
Drift meet the requirement of accurancy in 6 hours
Resolution
Waveform:
Value:
0.1 mmHg
1 mmHg
Sample flow rate
7.5
15
50
−
+
ml/min
Initialization time 30 s (typical)
Response time 2.9 s (typical)
Delay time 2.7 s (typical)
AwRR measurement range 0 to 150 BrPM
AwRR measurement
precision
0 to 70 BrPM:
70 to 120 BrPM:
121 to 150 BrPM:
±1 BrPM
±2 BrPM
±3 BrPM
Apnea alarm delay AwRR: 10 to 40 s
* Precision applies for breath rates of up to 80 bpm. For breath rates above 80 bpm, accuracy
complies with EN ISO 21647/ISO 21647/ISO 9918 (4 mmHg or ±12% of reading whichever is
greater) for EtCO2 values exceeding 18 mmHg. To achieve the specified accuracies for breath
rates above 60 breaths/minute, the Microstream® FilterLine H Set for Infant/Neonatal (p/n
006324) must be used.The accuracy specification is maintained to within 4% of the values
indicated in the above table in the presence of interfering gases according to EN ISO
21647/ISO 21647 Section Eleven, Part 101.
