9.3 CC-Link utility
9.3.5 Operating Parameter setting screen
9 - 73
9
UTILITY OPERATION
10
FUNCTIONS AND
PROGRAMMING
11
OVERVIEW OF
MULTIPLE CPU
SYSTEM
12
MULTIPLE CPU
SYSTEM
CONFIGURATION
13
MULTIPLE CPU
SYSTEM
CONCEPT
14
COMMUNICATIONS
BETWEEN CPU
MODULES
15
PARAMETERS
ADDED FOR
MULTIPLE CPU
16
PRECAUTIONS FOR
USE OF AnS SERIES
MODULE
(To next page)
Table9.49 Explanation of Parameter setting screen
Item Description
Modules
Set the number of CC-Link modules to be controlled by the C Controller module.
Selecting " (Blank)" is recognized as no setting (Setting clear).
(Initial value: " (Blank)" , Setting range: 1 to 8, " (Blank)" )
Target module
Select the module for which parameters are set. (Initial value: 1, Setting range: 1 to 8)
Refer to the following for details of the number assigned to this item.
This section (1)(a)
Start I/O No.
Set the start I/O No. of the CC-Link module.
(Setting range: 0 to FE0H (Note that duplication with the start I/O No. set to another CC-
Link module is not allowed.))
Channel No.
Set the channel No. of the CC-Link module.
Use the value set here when opening the channel from the Device monitor utility or user
program (MELSEC data link function).
(Setting range: 81 to 88 (Note that duplication with the channel No. set to another CC-
Link module is not allowed.))
button
Sets the operational setting and station information setting parameters to the initial
values.
button
Checks for any setting error.
Module information
Other station monitor Online operation
Parameter setting
Target setting Test
Default
Check
To Next Page
