18.3 Actions for Lit/Flashing ERR. LED

TROUBLESHOOTING

Table18.3 Error codes (Continued)

Error code Error message Error information

LED status

CPU operation status

RUN ERR.

1414 CONTROL-BUS.ERR.

Module No.

Off Flashing Stop

1415 CONTROL-BUS.ERR. Base No. Off Flashing Stop

1416 CONTROL-BUS.ERR.

Module No.

Off Flashing Stop

1500 AC/DC DOWN On Off Continue

1510 SINGLE PS.DOWN Base No./Power supply No. On On Continue

1520 SINGLE PS.ERROR Base No./Power supply No. On On Continue

1600 BATTERY ERROR On On Continue

* 1 The error information (module No.) stored in "Event information" on the <<Event history>> tab of the C Controller setting utility is

displayed as given below.

"Error information: XX - YYY"

XX (DEC.): Slot No. (0 to 63), CPU No. (1 to 4)

YYY (HEX.): Start I/O No. 16 (000 to 0FF, 3E0 to 3E3)
