Double Drive Gear
Air Blow Valve
Feed Clutch
Feed Bin Control
PCB
Morgana DocuMaster MFC - Service Manual 129
4. Service Procedures - Replace Components - Suction Feed Bin
Figure 4.122 Feed Bin RH Side Plate - Blow Valve Removed
Figure 4.123 Suction Feed Bin Emitter/Sensor Cable Ties
Emitter
Sensor
Sensor Housing
Rivet
Figure 4.124 Suction Feed BIn Emitter/Sensor
Rivet
Sensor Housing
Emitter
Sensor
Spacer
Lower Paper Guide
Figure 4.125 Emitter/Sensor Detail - Exploded View
