Morgana DocuMaster MFC - Service Manual 179
4. Service Procedures - Replace Components - Electrical Cabinet
4
4.12.8 Replace the 5V/24V PSU
Tools:

• Screwdriver: Pozidriv No. 2.
Before you start:
• Remove the electrical cabinet cover (See Section 4.2.12).
Step Action Information
1 Disconnect the cable con
connectors from the 5V/24V PSU
2 Disconnect the earth wire from the
from the 5V/24V PSU.
3 Remove the four screws that
att
ach the 5V/24V PSU to the
electrical cabinet.
4 Lift the 5V/24V PSU from the
electrical cabinet.
