6. General Procedures
6.1 MFC Specifications
Multi-Feed Creaser System
Configuration 4 Feed Bins (3 suction bins, 1 friction bin)
Minimum sheet size 210mm x 140mm
Maximum sheet size 450mm x 320mm
Maximum book thickness 23 sheets 0.11mm (80gsm)
Friction Feed Bin
Speed Up to 7200 sph (sheets per hour)
Capacity 40mm
Stock range 0.11mm - 0.35mm (80gsm - 300gsm)
Suction Feed Bin
Speed Up to 5000 sph (sheets per hour)
Capacity 45mm
Stock range 0.11mm - 0.24mm (80gsm - 240gsm)
Creaser Module
Number of creases 1 (centre of book) 2 x optical hinge creases
Hinge Range 4mm - 12mm from the book centre (cover only)
System Information
Dimensions L1760mm x W720mm x H2125mm
Weight 450Kg
Power Requirements 240v 50Hz / 115v 60Hz
Note: The
booklet production speed depends on sheet size,
crease selection and mode of operation selected.
