Morgana DocuMaster MFC - Service Manual 193
6. General Procedures - MFC System Data Sheet
6
6.2 MFC System Data Sheet
Model Morgana Multi-Feed Crease - creasing and booklet-making system
Description Creasing and booklet-making system for digit
al printers. Includes
DynaTilt creaser with rotary suction feeders, friction insert feeder and
gathering area module. Booklet maker, trimmer, 2-knife trimmer*, spine-
former. (*options)
Operating Conditions 10-35 °C at 35-85% relative humidity
Definitions MFC: Multi-Feed Creaser
BMP: BookMaster Pro
TMP: TrimMaster Pro
ASM: Automatic SpineMaster
Dimensions (installed system) MFC, BMP, TMP & ASM
Width 720mm
Length 1760mm (2500mm necessary to give access to booklet-maker)
Height 2125mm (1890mm without CAP)
Weight 450Kg
Electrical - 230V MFC & CAP BMP & TMP ASM
Voltage 230V (208-254V) 230V (208-254V) 230V (208-254V)
Frequency 50Hz 50Hz 50Hz
Current 8.0A 3.5A 3.0A
Protection Fuse CAP: 10.0A
MFC: 2 x 7.0A
5.0A 5.0A
Power Consumption Operation
Standby
1400VA
50VA
700VA
30VA
700VA
30VA
Mains Connection removable cable and
plug
removable cable
and plug
removable cable
and plug
Electrical - 115V MFC CAP BMP & TMP ASM
Voltage 115V (105-127V) 115V (105-127V) 115V (105-127V)
Frequency 60Hz 60Hz 60Hz
Current 8.5A 4.7A 10.0A 4.8A
Protection Fuse 2 x 10.0A 10.0A 10.0A 10.0A
Power Consumption Operation
Standby
975VA
30VA
550VA
20VA
510VA
30VA
550VA
30VA
Mains Connection 2 x removable cable and
plug
(MNEMA 5-15)
2 x removable cable
and plug
(MNEMA 5-15)
2 x removable cable
and plug
(MNEMA 5-15)
Safety Class I I I
Protection Class IP 20 IP 20 IP 20
Sound pressure level (at
operator/
bystander position)
Radio Interference
Radiation
Ozone Emission
Standby: 0 dB (A). In use: 74 dB (A)
typical, 80dB (A) impulse peak
Complies with Directive 89/336/EEC
Not applicable
Negligible (predicted peak ozone concentration 0.004ppm)
Room volume
Room ventilation
No special requirements
No special requirements
