7. Electrical and Control System - Fuses
214 Morgana DocuMaster MFC - Service Manual
7. Electrical and Control Systems
7.1 Fuses

Warning: Always set the main input switch to the OFF(0) position before you remove
the MFC fixed covers or change the main input fuses. T
he MFC uses double-pole/
neutral fusing (i.e. two fuses). If one of the main input fuses is defective, remaining
circuits can continue to be live. If you do not obey this instruction it could cause severe
injury or death.
7.1.1 MFC Fuses
A list of fuses used in the MFC is shown in the table that follows:
Location Fuse Function Rating
CAP Module
Mains Input - Main line fuse x 1 10.0A, HRC Quick-acting, F
DRV Module
Main Input - Main line fuse x 2 240V - 7.0A, HRC Quick-
acting, F
115V - 10A, HRC Quick-
acting, F
Interface PCB F1 9V rail for data 3.15A, Glass Anti-surge, T
F2 28V rail for clutches,
solenoids, etc.
6.3A, Glass Anti-surge, T
F3 not used 2.0A, Glass Anti-surge, T
Motor Drive PCB F4 not used 240V - 2.0A, HRC Quick-
acting, F
115V - 4.0A, HRC Quick-
acting, F
F5 Blower Motor 240V - 5.0A, HRC Quick-
acting, F
115V - 10.0A HRC Quick-
acting, F
Low Voltage
T
ransformer
F6 Transformer 3.15A, HRC Anti-surge, T
High Voltage
T
ransformer
- Anti-static
Transformer
500mA, Glass Quick-acting,
F
Electrical Cabinet
Top Fuse - 24V / 48V PSU 4.0A, HRC Anti-surge, T
Centre Fuse - 5V / 24V PSU 3.15A, HRC Quick-acting, F
Bottom Fuse - not used not used
