MOTOROLA
MPC823e REFERENCE MANUAL
22-1
ELECTRICAL
22
CHARACTERISTICS
SECTION 22
DC ELECTRICAL CHARACTERISTICS
This section contains basic information about power considerations, thermal characteristics,
layout practices, and DC timing specifications for the MPC823e.
22.1 MAXIMUM RATINGS (GND = 0V)
Note:
So that we may provide you with the most current information, the
MPC823e AC
Electrical Characteristics
(part number MPC823EELE/D) can be accessed from
our website at www.motorola.com. If you do not have internet access, please
contact your local Motorola sales office for a printed copy.
RATING SYMBOL VALUE UNIT
Supply Voltage VDDH -0.3 to 4.0 V
VDD -0.3 to 4.0 V
KAPWR -0.3 to 4.0 V
VDDSYN -0.3 to 4.0 V
Input Voltage (JTAG and GPIO) VIN -0.3 to 5.8 V
Input Voltage (All other pins) VIN -0.3 to 3.3 V
Operating Temperature T
A
0 to 70˚
or
-40˚ to 85˚
˚C
Storage Temperature Range T
STG
-55 to +150 ˚C
1. Functional operating conditions are given in
Section 22.4 DC Electrical
Characteristics (VCC
= 3.0 - 3.6 V)
. Absolute maximum ratings are stress
ratings only, and functional operation at the maxima is not guaranteed.
Stress beyond those listed may affect device reliability or cause permanent
damage to the device.
2.
CAUTION
: The JTAG and GPIO input voltages cannot be more than 2.5 V
greater than supply voltage, this restriction applies also on “power-on” as well
as on normal operation.
3. 5 Volt friendly inputs are inputs that tolerate 5 volts for JTAG and GPIO pins.
