Memory Controller
MOTOROLA MPC823e REFERENCE MANUAL 15-51
MEMORY CONTROLLER
15
MEMORY CONTROLLER
15
G0H—General-Purpose Line 0 Higher
This field defines the state of the GPL0
signal during clock phase 4.
10 = The GPL0
signal is asserted at the trailing edge of GCLK1.
11 = The GPL0
signal is negated at the trailing edge of GCLK1.
00 = The GPL0
signal is driven at the trailing edge of GCLK1 as defined in the G0CLx
field of the MxMR.
G1T4—General-Purpose Line 1 Timing 4
This bit defines the state of the GPL1
signal during clock phases 1 through 3.
0 = The GPL1
signal is asserted at the trailing edge of GCLK2.
1 = The GPL1
signal is negated at the trailing edge of GCLK2.
G1T3—General-Purpose Line 1 Timing 3
This bit defines the state of the GPL1
signal during clock phase 4.
0 = The GPL1
signal is asserted at the trailing edge of GCLK1.
1 = The GPL1
signal is negated at the trailing edge of GCLK1.
G2T4— General-Purpose Line 2 Timing 4
This bit defines the state of the GPL2
signal during clock phases 1 through 3.
0 = The GPL2
signal is asserted at the trailing edge of GCLK2.
1 = The GPL2
signal is negated at the trailing edge of GCLK2.
G2T3—General-Purpose Line 2 Timing 3
This bit defines the state of the GPL2
signal during clock phase 4
0 = The GPL2
signal is asserted at the trailing edge of GCLK1.
1 = The GPL2
signal is negated at the trailing edge of GCLK1.
G3T4—General-Purpose Line 3 Timing 4
This bit defines the state of the GPL3
signal during clock phases 1 through 3.
0 = The GPL3
signal is asserted at the trailing edge of GCLK2.
1 = The GPL3
signal is negated at the trailing edge of GCLK2.
G3T3—General-Purpose Line 3 Timing 3
This bit defines the state of the GPL3
signal during clock phase 4.
0 = The GPL3
signal is asserted at the trailing edge of GCLK1.
1 = The GPL3
signal is negated at the trailing edge of GCLK1.
