PCMCIA Interface
17-14 MPC823e REFERENCE MANUAL MOTOROLA
PCMCIA INTERFACE
17
CB_EBVD2—Card B Enable for Battery Voltage/SPKR
0 = Disable interrupt on any change in the relevant pin.
1 = Enable interrupt on changes in the relevant pin.
CB_EBVD1—Card B Enable for Battery Voltage/STSCHG
0 = Disable interrupt on any change in the relevant pin.
1 = Enable interrupt on changes in the relevant pin.
Bit 23—Reserved
This bit is reserved and must be set to 0.
CB_ERDY_L—Card B Enable for RDY/IRQ
Low
0 = Disable interrupt on any change in the relevant pin.
1 = Enable interrupt on changes in the relevant pin.
CB_ERDY_H—Card B Enable for RDY/IRQ
High
0 = Disable interrupt on any change in the relevant pin.
1 = Enable interrupt on changes in the relevant pin.
CB_ERDY_R—Card B Enable for RDY/IRQ
Rising Edge
0 = Disable interrupt on any change in the relevant pin.
1 = Enable interrupt on changes in the relevant pin.
CB_ERDY_F—Card B Enable for RDY/IRQ
Falling Edge
0 = Disable interrupt on any change in the relevant pin.
1 = Enable interrupt on changes in the relevant pin.
Bits 28–31—Reserved
These bits are reserved and must be set to 0.
