4.5
Connectors and Pin Assignment of Expansion
Heads
CAUTION: Do not connect a TELCO remote cable to the Ethernet RJ50 port.
Figure 65: Single Remote Expansion Head – Front View and Connector Location
1
Table 73: Associated Components
Number Description
1 10-pin RJ50 Ethernet Connector, Front View
NOTE: This is a connector to the Control
Head and not to a microphone.
Figure 66: Dual Remote Expansion Head – Front View and Connector Location
321
MN009998A01-AA
Chapter 4: Connectors and PIN Assignment
101
