Motorola MXM600 - Figure 50: Connection Plan for the Ignition Sense Cable; Table 60: Associated Components

Figure 50: Connection Plan for the Ignition Sense Cable
1
2
3
4
5
6
7
8
9
10
1
2
Table 60: Associated Components
Number Description
1 Junction Box 10 Pin Accessory Plug
2 To Ignition Switch, Ignition Switch Cable, Switched Battery Voltage
