Motorola MXM600 - Figure 28: Accessories Expansion TSCH Y-Cable; Table 47: Associated Components

Manual installation is required. Clamps are fixed with 2-turns of wire.
The Accessories Expansion (Telephone Style Control Head) TSCH Y-Cable (PMKN4134_) allows you to
connect extra accessories.
Figure 28: Accessories Expansion TSCH Y-Cable
1
5
5
2 3 4
6
7
8
Table 47: Associated Components
Nu
mb
er
Item
Description
1 Telephone Style Control Head -
MN009998A01-AA
Chapter 3: Radio Installation
61
