Motorola MXM600 - Figure 52: Terminal into Low or High Profile Trunnion (GLN7324_; GLN7317_); Figure 53: Terminal into Enhanced Trunnion Kit (PMLN8620_); Table 63: Associated Components

Figure 52: Terminal into Low or High Profile Trunnion (GLN7324_ / GLN7317_)
1
1
3
2
2
Figure 53: Terminal into Enhanced Trunnion Kit (PMLN8620_)
1
4
2
2
1
Table 63: Associated Components
Number Part Number Description
1 0302637Y01 Wing screws included in the Trunnion Mount Kit.
2 0400002647 Washer 2x
3 GLN7324_, GLN7317_ Trunnion
4 PMLN8620_ Enhanced Trunnion
MN009998A01-AA
Chapter 3: Radio Installation
87
