2.3.1
DC Power Cables
Table 31: DC Power Cables
Number Description Rating
PMKN4289 Power Cable to Battery with fuse
15 A
12 V Power Cable to Battery, Length: 1.0 m
PMKN4243_ Power Cable to Battery with fuse
15 A
12 V Power Cable to Battery, Length: 3.1 m
PMKN4275_ Power Cable to Battery with fuse
15 A
12 V Power Cable to Battery, Length: 6.2 m
6580283E06 Fuse 15 A for Power Cable
6580283E02 Fuse 4 A for Ignition Sense Cable
CP000122A01 Fuse 2 A for Y-Cable
6580283E03 Fuse 5 A for Y-Cable
CAUTION: In cases of blown fuses, replace only with fuses of identical value. Never insert ones of
different values.
NOTE: For more information on ignition cables, see Installing Ignition Sense Cable on page 36. The
Ignition Sense Cable allows your radio to be turned on and off by the vehicle ignition switch.
2.4
Installing Ignition Sense Cable
The Ignition Sense Cable (PMKN4120_) allows the terminal to be turned on and off by the vehicle ignition
switch.
CAUTION: In cases of blown fuses, replace only with fuses of identical value. Never insert ones of
different values. Ensure that the fuse is removed during cable installation.
Procedure:
1. Plug the lead of the ignition sense cable that has a terminal crimped on it into #25 socket of the
accessory plug.
2. Route and secure the cable with the attached tie wrap.
3. Connect the other lead of the accessory cable to the ignition switch of the vehicle.
4. Insert the fuse into the fuse holder and close the cover.
MN009998A01-AA
