Motorola MXM600 - Mechanical Parts List for IP67 Remote Mount Installation; Figure 42: Downward Movement; Figure 43: IP67 Remote Ethernet Control Head (RECH) Mounted in a Trunnion

Figure 42: Downward Movement
3.5.2
Mechanical Parts List for IP67 Remote Mount
Installation
Figure 43: IP67 Remote Ethernet Control Head (RECH) Mounted in a Trunnion
1
3
3
155+/-0.1 mm
33 mm
2
MN009998A01-AA
Chapter 3: Radio Installation
75
