Motorola MXM600 - Model Specifications; Table 6: General Specifications

Type
No.
Sales Model No. Region Short Description Model
ANM79TFT6TZ5
AN
MXM600 Single Remote 350-470 MHz
MTC953DE
M2
WARNING: Single Remote Expansion Head (SREH), Dual Remote Expansion Head (DREH), or
Databox Expansion Head (DEH) are only compatible with Ethernet Remote Heads. Do not mix
Ethernet control heads with non-Ethernet control heads. Ensure the use of appropriate RJ50 Ethernet
cables for connecting a SREH, DREH or DEH with a Telephone Style Control Head (TSCH), IP54
Remote Ethernet Control Head (RECH), IP67 RECH, or for connecting a DREH with another DREH.
Incorrect connections can damage the transceiver.
1.4
Model Specifications
Technical information can change without further notice.
Table 6: General Specifications
Parameter Value
ETSI ETSI 300 394 1
MXM600 350–
470 MHz
MTC953DE
Temperature
Range for Trans-
ceiver
Operating –30 °C to +60 °C (+70 with limited performance)
Storage –40 °C to +85 °C
Power Supply Minimum 10.8 VDC
Nominal 13.2 VDC
Maximum 15.6 VDC
Maximum Current Approximately 5.5 A
GNSS Perform-
ance
Acquisition Sensi-
tivity
GPS: –145 dBm (guaranteed), –146 dBm (typical)
Tracking Sensitiv-
ity
GPS: –163 dBm (guaranteed); –164 dBm (typical)
BeiDou: –155 dBm (guaranteed); –156 dBm (typical)
Glonass: –157 dBm (guaranteed); –160 dBm (typical)
Galileo: –155 dBm (guaranteed); –157 dBm (typical)
Bluetooth Bluetooth Class 1, 90 m range (line-of-sight)
Wi-Fi 2.4 GHz
5 GHz
Control Head Dimension and Weight
Control Head Dimension H x W
x D (mm)
Weight (g)
Dash/Desk Mount Transceiver and Control Head 60 x 188 x 200 1530
Control Head 60 x 188 x 31 235
MN009998A01-AA
Chapter 1: Model Information and Accessories
17
